Old 11-26-2006, 08:15 PM   #1
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default How to setup a 15g/16t/18t/19t for RWD

i know a smart man would not do this as it MIGHT hurt my selling of turbo business BUT i'm more about helping people so here goes

ok so first you get the turbo unbolt everything, and take it apart remove the guide pins ... haha and clean it (i have pics of this but i need to find them so i'll add them later)

and NOW from there you assemble it pics should speak more than words .. if you have any questions please ask





notice the drilled out hole... you need to remove the two studs and drill out the holes so it fits a 90+





now once you figure out the clocking of the center you drop it in and reinstall the snap ring (two ways to align it one is by eye and the other i will NOT tell)




remember the oil feed hole goes on TOP


now it is easy .. just clock/align the turbine with the center and bolt it on .. i have two ways of doing this one is by eye and the other i will not tell because i am a punk




once it is all together a quick and easy bracket will do the job(it is really thin and there is a nut welded onto the back of the actuator to space it off just a little to keep the thing bracket from bending along with should be enough toget some good preload and adjustment of the arm



you can see the nut i welded on for spacing


so there ya go .. does that help anyone? or make anyone want to buy a turbo from me? hehe

one key that i might not of mentioned was that if you are swaping in a Mitsu TD04HL into a 90+ turbo car will drop in with all of the OEM oil feed and return lines unless your car has a T25 in which the feed does work but requires one hell of a custom WG setup

if you have an older turbo car you WILL need to get the mitsu oil feed and return lines along w/ the water cooling lines and banjo bolts off another 90+ turbo car

OR you could build your own custom line .. which there are other threads with that info in that i will link here once i find them
__________________
Chip Feedback Thread / PM LH 2.4 Chip Prices

Last edited by thelostartof; 02-21-2007 at 11:14 AM..
thelostartof is offline   Reply With Quote
Old 11-26-2006, 08:19 PM   #2
Oreo931
Post-It-Note on wheels

Oreo931's Avatar

Join Date: Jul 2006
Location: DE
Default

yes! i am going to be buying a turbo from you after/during my winter break...i believe it starts the 14th and i will start working soon after that...so be prepared for me to be buying a turbo from you between mid december-late january! i cant wait.
__________________

'95 854 T5-R Manual - Garage Queen
'97 855R - Daily Driver
CarDomain
Oreo931 is offline   Reply With Quote
Old 11-26-2006, 08:20 PM   #3
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

oh and those who like pimp my ride .. you can do the same your turbo turbo with a little metallic flake paint

thelostartof is offline   Reply With Quote
Old 11-26-2006, 08:37 PM   #4
PetesDustyVolvo
one car, two bicycles

PetesDustyVolvo's Avatar

Join Date: May 2003
Location: caliper land
Default

snap rings for the mfl not really

man this makes me think maybe i should rewrite the fuel injector guides when I get home

gj mike
PetesDustyVolvo is offline   Reply With Quote
Old 11-26-2006, 09:30 PM   #5
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

snap rings are so so so easy

1000x easier than those bolts on teh t3 ... i hate removing those. i took apart like 3 t3's this weekend, and two 15g's ...mmm turbos
thelostartof is offline   Reply With Quote
Old 11-26-2006, 10:09 PM   #6
PetesDustyVolvo
one car, two bicycles

PetesDustyVolvo's Avatar

Join Date: May 2003
Location: caliper land
Default

Quote:
Originally Posted by thelostartof View Post
snap rings are so so so easy

1000x easier than those bolts on teh t3 ... i hate removing those. i took apart like 3 t3's this weekend, and two 15g's ...mmm turbos
dont tell anyone there are only 5/6 bolts on my exhaust housing
PetesDustyVolvo is offline   Reply With Quote
Old 11-27-2006, 10:38 AM   #7
JW240
All idiot, no savant

JW240's Avatar

Join Date: Aug 2004
Location: The Netherlands, Europe
Default

ok thanks for the writeup. There is a 15G with 20k miles for sale at the moment, maybe i'll pick it up...

Isnt it possible/easyer to use the actuator of a 13C?
__________________
240 | 1991 | 326 KKm | B230F+T | Cossie T3 60/63 | M90 | TrueTrack
Husaberg FE450 '12



Quote:
Originally Posted by Redwood Chair View Post
Don't forget about properly seasoning it on HF jackstands for a couple years whilst dreaming about big powah 'goals'.
JW240 is offline   Reply With Quote
Old 11-27-2006, 11:31 AM   #8
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

not really, i'll get some pics of a 13c actuator i have here, the issue is the 13c actuator is weaker than the 15g one .. so up to you to use what you want. and the 13c one will not just bolt to the 15g it still requires a bracket to fit
thelostartof is offline   Reply With Quote
Old 11-27-2006, 11:42 AM   #9
smith_t240
Abnormally Aspirated

smith_t240's Avatar

Join Date: Jun 2004
Location: Milwaukee, WI 53211
Default

Mike does awesome work, if you can't tell.
__________________
Smith T.

83 244Ti white project car
91 244DL+T gold 241k, winter beater, soon to be replaced with a truck
07 S60R 6spd black the better DD

Quote:
Originally Posted by Ktown_Brick View Post
I stubbed my toe while getting a beer this afternoon. I feel both your guy's pain. What a crappy day, ohh well, tomorrow can't get much worse for me
smith_t240 is offline   Reply With Quote
Old 11-27-2006, 02:38 PM   #10
ikyikthe1st
Board Member

Join Date: Feb 2006
Location: South Carolina
Default

I definitely think I'll be buying one of these...after I find a car to put it in, of course. :D
ikyikthe1st is offline   Reply With Quote
Old 11-27-2006, 02:58 PM   #11
Hank Scorpio
Chubfest 2009 Survivor

Hank Scorpio's Avatar

Join Date: Nov 2002
Location: The neighborhood with the ******* guitar player.
Default

the snap ring on holsets are like 200000# of tension. OMG
__________________
Hank Scorpio is from the Simpsons. You can call me Doug ;)
Will trade guitars/guitar parts for go fast goodies or stuff I need. Just PM.
www.kauerguitars.com the second best way to upset neighbors and alienate people.
History: Car 1 (242) | Car 2 (t5r) | Car 3 (255)
Hank Scorpio is offline   Reply With Quote
Old 11-27-2006, 02:59 PM   #12
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

send me a holset i'll see if i can remove it
thelostartof is offline   Reply With Quote
Old 12-06-2006, 09:13 AM   #13
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

bump for the new working TB
thelostartof is offline   Reply With Quote
Old 12-06-2006, 09:52 AM   #14
Mesoam
Board Member

Mesoam's Avatar

Join Date: Jul 2004
Location: CT
Default

you should just pickup a bunch of 90+ mani's and sell the turbo/mani's ready to bolt on...
__________________
08 XC90 R-Sport
Mesoam is offline   Reply With Quote
Old 12-06-2006, 10:45 AM   #15
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

i have like 3 90+ here so

what i need to do is find a place to get 8v head flanges and make custom manifolds with these turbos and sell bolt on manifold/turbo/downpipe setups
thelostartof is offline   Reply With Quote
Old 12-06-2006, 11:32 AM   #16
Aoder1
Board Member

Join Date: Jun 2006
Location: Charlotte
Default

holy cow, i want a 15g, but i have no funds, but i will seek here for when i have $$$$
Aoder1 is offline   Reply With Quote
Old 12-06-2006, 05:37 PM   #17
BDKR
Section 9

BDKR's Avatar

Join Date: Nov 2003
Location: Horizons Cave
Default

Just as an addendum, make sure you get the clocking right or else you'll find that your oil return is in the way of wg actuator arm. If the CHRA is allready clamped onto the turbine housing, you can loosen the clamp (don't remove it) then rotate the CHRA a little. You can also loosen the snap ring a little and rotate the comp housing without removal.

Can you tell I had to this a little bit?

Good write up Mike!
__________________
Quote:
For all you Dijkstra fanboys:

Knuth also cites a letter sent to him by Dijkstra, in which the latter adds some nuance to this earlier statements: "Please don't fall into the trap of believing that I am terribly dogmatical about [the go to statement]. I have the uncomfortable feeling that others are making a religion out of it, as if the conceptual problems of programming could be solved by a single trick, by a simple form of coding discipline!"
BDKR is offline   Reply With Quote
Old 12-06-2006, 05:45 PM   #18
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

well if you have a 13c handy you can clock it off that, or just throw it on the car and mark it where it SHOULD be with the oil return bolted in and no compressor housing on it .. and then go from there and make teh WG bracket
thelostartof is offline   Reply With Quote
Old 12-20-2006, 05:46 PM   #19
B Mac66
Board Member

B Mac66's Avatar

Join Date: Sep 2005
Location: Bethlehem, CT
Default

i have a 95 redblock with 60k miles on it sitting on my garage floor....manifold is on it, but no turbo...is this something i should look into?? the 15g is off an 850??
B Mac66 is offline   Reply With Quote
Old 12-20-2006, 05:51 PM   #20
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

yes it is a very nice upgrade for pretty cheap

and yes the conical 15g's were off the 94-96(early) 850's
thelostartof is offline   Reply With Quote
Old 12-20-2006, 07:54 PM   #21
Unregistered
Guest

Default

I want to purchase one of your turbos and a down pipe if possible. I cannot pm you because I am registered but unable to post. I tried to register again, but I never get the confirmation email to activate me. Can you please give me some other way to contact you? Also, if someone is reading this that can fix my registration, I would appreciate it as this is causing a delay in my Brick's progress...and my need for boosted goodness ;)

Thanks,
Doug
  Reply With Quote
Old 12-20-2006, 07:55 PM   #22
Unregistered
Guest

Default

I forgot...my registered name is NC244GLT
  Reply With Quote
Old 12-20-2006, 08:11 PM   #23
thelostartof
unbalanced chemical

thelostartof's Avatar

Join Date: Jun 2002
Location: Apache Junction, AZ
Default

right now the only turbo i have is a fully rebuilt 15g that i still need to setup(it is being rebuilt right now) so ... $450 dshipped for that one

and you can contact me @ thelostartof at thelostartof.net
thelostartof is offline   Reply With Quote
Old 12-20-2006, 09:00 PM   #24
Unregistered
Guest

Default

So that one would be basically "new" condition clocked to RWD? Do you have DP's available yet?
  Reply With Quote
Old 12-20-2006, 09:10 PM   #25
amargill19?
Barry McCockiner

amargill19?'s Avatar

Join Date: Aug 2005
Location: 604
Default

kool. so whats the ideal turbo for a +T... on an 89 b230f+t with greentops and lh2.4 244?

not runnign super high boost levels, but something to flow well and create boost at lower rpms. (if that makes any kind of sense?)

mitsu? garett? water cooled? oil cooled.... i know nothing 'bout turbos except that my buddies garette t2 on the sunterd had to be rebuild and had a sticky wastegate.

my idea is to slowly collect crap from 700's/900's until i have time/patience to do this

i'll will also think of you when i'm looking for a turbo, i wouldnt wanna pull a junkyard one.. rebuilt me thinks would be good

- Amar
__________________
Quote:
Originally Posted by Dan Wood View Post
Now, two years later, after a move to Oklahoma, a job in a potato salad plant, and many other assorted ventures, I have plans to visit Paraguay.
amargill19? is offline   Reply With Quote
